These carbon steel fuel tank oil trailer specification is just for your reference. Our factory can manufacture any kinds of specification carbon steel fuel tank oil Trailer as your request.
For your transport / logistic needs, feel free to contact us using our phone number, email, or you can visit our website for more information, please follow us on Facebook, Linkedin, Youtube, Instagram, or Pinterest.
check more on our Product List.
| TRAILER MODEL | Carbon Steel tank trailer |
| OUTSIDE DIMENSION | 11500mm*2500mm*3990mm ( Exact size depends on the final design) |
| LOADING CAPACITY | 45,000 litres /45 CBM (can be design) |
| AXLE | 3, FUWA /BPW |
| SUSPENSION | Spring /Airbag(booster) |
| BRAKE SYSTEM | WABCO |
| Compartments | 1 (can be design) |
| TYRES | 13 (12 +1 spare), 12R22.5 |
| LANDING GEAR | 28 Ton |
| KING PIN | JOST, 50 (2") /90 (3.5") |
| MAIN BEAM | 500mm, 14/16 |
| Tanker Body Material | 5mm Q235 carbon steel |
| End Plate | 6mm Q235 carbon steel |
| Manhole Cover | Cabon steel, 500mm |
| Bottom Valve | Aluminum API Pneumatic Bottom Valve |
| Discharging Valve | Diameter is 3 or 4 inch |
| Cat Walk | With (Common model or special design) |
| Discharging Pipe | 4” rubber hose, 2 pcs, 6m/each |
| ELECTRICAL | 24V, 7 ways(7 wire harness) |
| ACCESSORY | One tooling box with a set of standard trailer tool |
